ERGO-PWPLA, Ergomatic Drum transporter Full Powered
Product features

Industry's first fully powered portable Parrot-Beak drum handler! This new counter-balanced drum transporter employs battery powered travel/lift drives for loading, lifting, retrieving and storing all steel, plastic and fiber drums. Ability to climb slope to 6 degrees and fully regenerative braking function! Handles 350kg with any open top or tight head drum with fully powered lift and lower cycle! Cushioned belt cradle protects drum during transport, lift and lower cycle. Powerful 24V battery system with charger make safe work for any male or female operator.

 Product Overview

The ERGO-PWPLA series is a stand-on electric drum truck designed for lifting and transporting drummed materials on flat, solid surfaces. It features rapid adjustment for drums of varying heights, ensuring easy clamping and handling. The unit is equipped with a specialized clamping mechanism that automatically grips and releases, guaranteeing a secure hold during transport for safe and reliable operation. Its standout features are the electric travel and lifting systems, which allow for the effortless movement and elevation of drums without the need for manual force.



Specifications



ModelERGO-PWPLA
Weight612KG
Capacity350KG
Dimensions1230mm (L) x 710mm (W) x 1220mm (H)
Lifting height 490mm
Minimum turning radius 1100mm
Warranty12 months against any defect in parts and workmanship
OptionsOptional wheels for various floor conditions. Custom designs for non-standard drums or applications
